25~26 Sand & Dust Tester.pdf
Stainless Steel Environmental Test Chamber Sand and Dust Tester for Electrical Appliance
Application:
Sand and dust test chamber is used for dust test including floating dust and cyclone dust: for all kinds of automobile parts, such as, automobile lamps, meter, safe belt, seat regulator, dirt-proof boot of electrical appliance, lockers etc.
Features:
1. Adopt strong spray dust device, the user can operate independently for No.1 floating dust, No.2 floating dustt,No.3 floating dust on the gauge panel.
2. Adopt vibration device; spray dust's density can be the same every time.
3. Precision collection for dust concentration, Can reduce the misestimate concentration because of improper operation
4. Meet DIN, IEC, GB, ISO, JIS standard
5. Control system: be connected with and monitored by computer
6. Convenient design for dust cleaning.
7. synchronous resonance function to ensure of the uniformity of dust concentration
Technical parameters:
| Model | DT-C1 | DT-C2 |
| Remark | C for cyclone dust |
Concentration of Sand
and Dust | C1: 5000mg/m3
5m/s | C2: 100mg/m3
10m/s |
Internal Dimension
WxHxD (mm) | 1000x1000x1000 |
External Dimension
WxHxD (mm) | 1650x1850x1450 |
| Temperature Range | RT(25℃±15℃), or lab temperature |
| Humidity Range | 35~90% R.H., or lab humidity |
| Talcum Powder Dosage(Kg/m ²) | 2 ~4 |
Metal Net Mesh Standard
Diameter (μm) | 50 |
Diameter Between Metal
Wires (μm) | 75 |
Powder Spray & Dust
Fall Mode | 1. Dust fall freely: adopt centrifugal fan to blow the sand or dust to 1/5 of roof, fall freely.
2. Blow the sand or dust: pressure spray dust from the bottom, multi- steps pressure adjustable |
| Test Standard | Meet JIS, ISO, IEC60529,DIN40050,GB2423 test standard |
| Power | AC 220V, 1∮ 3 Lines, 50/60HZ ; |
FAQ:
1. Are your company a trading one or a factory?
Factory ,28 years focusing on test instruments field,4 years exporting experience.
2. After an order is placed, when to deliver?
Generally about 20 workdays, If we have finished products, we can arrange shipment within 3 workdays.
Please be aware that our production lead times depend on specific items and item quantities.
3. What about the warranty with after - sales services?
12 months warranty.
After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.
4. What about the services and product' quality?
Service: OEM service,Design service,Buyer lable service.
Quality: Each instruments must be carried out 100% quality examination and test, the finished products must through a third party calibration institutions before shipping and delivery goods.
5. How to install and training?
If the products is easy to install and training, customers can learn the operation and maintenance manual to installation and use.
If the products is hard to use, customers can come ASLi factory to learn how to installation and use. And our engineers have a passport, we can go to overseas.
6.What's your main products?
Environmental chambers, temperature (humidity) chamber, PCT /Hast chamber (Highly accelerated stress test chamber),ESS chamber, Walk in stability chamber,Vacuum oven,Altitude chamber,vibration test system, mechanical shock tester,environmental combined vibration chamber,etc.
Any inquiries please feel free to contact us !
